Copper bonded Ground Rod with Ground Clamp
Copper bonded ground rod is made of high carbon steel core with molecular bonded copper outer layer. It has low earth resistance good conductivity strong anti corrosion performance and long service life.
Matching ground clamps are provided for easy connection with copper cables. This product is widely used in earthing and lightning protection projects for power stations transmission towers buildings communication base stations and industrial facilities.
Multiple diameter options range from 10mm to 20mm. Unit length can be customized from 1.0m to 2.5m. The copper layer thickness is 0.254mm which meets international earthing standards.
Specification
|
Model
|
Diameter(mm)
|
Copper layer thickness
|
Unit length
|
|
QD-CD10
|
10
|
0.254
|
1.0-2.5m/piece
|
|
QD-CD12
|
12
|
0.254
|
1.0-2.5m/piece
|
|
QD-CD13
|
13
|
0.254
|
1.0-2.5m/piece
|
|
QD-CD13.2
|
13.2
|
0.254
|
1.0-2.5m/piece
|
|
QD-CD14
|
14
|
0.254
|
1.0-2.5m/piece
|
|
QD-CD16
|
16
|
0.254
|
1.0-2.5m/piece
|
|
QD-CD17.2
|
17.2
|
0.254
|
1.0-2.5m/piece
|
|
QD-CD20
|
20
|
0.254
|
1.0-2.5m/piece
|
